AlphaPro can provide a wide variety of silicone products. Common application scenarios include electromagnetic shielding CIPG, sealing protection of components on PCBs, and reinforcement of FPCs. It has rapid positioning and excellent adhesion to multiple substrates. It also has excellent high-temperature resistance. At the same time, it can provide thermal management for heat sinks, memory and chips, power transistors and CPUs, etc., including potting protection for photovoltaic, wind power, energy storage systems and on-board charger inverters OBC.
*Shear Strength/MP data is based on common interface material to be attached. Please request if there is any other demand.
| NAME | MODEL | FUNCTION | COMP | Curing conditions | COLOR | Viscosity mPa.s |
Shear Strength Mpa |
Hardness shore |
| RTV Silicone | ASIR101W | Sealing protection | 1K | RT 7days | WHITE | 1000000 | AI:1.8 | 48A |
| ASIR102 | 1K | Half-Clear | 57000 | AI:1.5 | 23A | |||
| ASIR103B | Potting protection | 1K | Black | 40000 | AI:1.6 | 35A | ||
| Organic Silicone | ASIL201W | 2K 1:6 | RT 3days | WHITE | 3000 | / | 45A |
| NAME | MODEL | FUNCTION | COMP | Curing conditions | COLOR | Viscosity mPa.s |
Thermal conductive Factor | quality guarantee period @8-25℃ |
| Organic Silicone | ASIT201B | Thermal conductive potting | 2K 1:1 | Room Temperature | BLUE | 8133 | 3W | 6Months |
| ASIT202P | Light Pink | 2996 | 2W | |||||
| ASIT203G | Grey | 4570 | 1.5W | |||||
| ASIT204G | Grey | 3300 | 1W | |||||
| Thermally conductive silicone | ASITG201W/B | WHITE/BLUE | A:123000 B:78000 |
3.6W | ||||
| ASITG101 | 1K | N/A | Adjustable | Adjustable | 2W-8W | 12Months |
以上为行业常用标准规格，其他规格可根据需求提供；
上述数据在标准、稳定的实验室环境下测试获得，实际参数请按照实际应用场景数据。
*Data and spec above are the commonly used standard in the industry, for other spec can be provided according to your needs (please leave us message). And the data are obtained through testing in standard laboratory environment. For actual parameters, please refer to the data of the actual application scenario.
