MMA glue has characteristic of quickly establishing strength, reducing the holding time and improving assembly efficiency. It is suitable for bonding applications of metal interface materials. After the glue is cured, it has high hardness and high modulus.
*Shear Strength/MP data is based on common interface material to be attached. Please request if there is any other demand.
| NAME | MODEL | COMP. | Curing conditions | COLOR | OPEN TIME min |
Viscosity mPa.s |
Shear Strength Mpa |
| MMA | AMAC201 | 2K 10:1 | Room temperature |
A Comp:Blue |
3-5 |
A：83000 |
SUS：＞15 |
| AMAC202 | 2K 10:1 |
A Comp:Blue |
4-7 | A：60000 B：55000 |
SUS：＞15 | ||
| AMAC203 | 2K 10:1 |
A Comp:Blue |
5-7 | A：75000 B：60000 |
SUS：＞15 |
| NAME | MODEL | COMP. | Curing conditions | COLOR | Viscosity mPa.s |
Shear Strength Mpa |
|
UV Cured adhesive |
AUV101 |
1K |
Mercury lamp (electrodeless lamp) 1000mj/cm² or LED light source 365nm (395nm) 3000 - 6000mj. |
Light yellow translucent |
5200 | PC/PCB 12 PC/Fe 10 PVC/AI 8 |
| AUV102 |
1K |
1300 | PC/PCB 16 PC/PC 12 |
|||
| AUV103 |
1K |
73670 | PVC/PVC 8 PVC/AI 5 |
| NAME | MODEL | COMP | Curing conditions | COLOR | Viscosity mPa.s |
Shear Strength Mpa |
|
UV |
AUVM101 |
1K |
Mercury lamp (electrodeless lamp) 1000mj/cm² or LED light source 365nm (395nm) 3000 - 6000mj |
Light blue translucent |
1500 | PC/PCB 13 PC/Fe 9 |
| AUVM102 | 4000 | PC/PCB 12 PC/SUS 8 |
||||
| AUVM103 | 4000 | PC/PCB 15 PC/Fe 8 |
以上为行业常用标准规格，其他规格可根据需求提供；
上述数据在标准、稳定的实验室环境下测试获得，实际参数请按照实际应用场景数据。
*Data and spec above are the commonly used standard in the industry, for other spec can be provided according to your needs (please leave us message). And the data are obtained through testing in standard laboratory environment. For actual parameters, please refer to the data of the actual application scenario.
